115RE Rail Profile

Author : | Last Updated : 2024-03-13

115RE Rail

The 115RE rail is a specific type of rail profile commonly used in railway construction. The designation “115RE” refers to the rail’s weight per yard, with 115 pounds being the approximate weight of one yard (3 feet) of the rail. This rail profile is widely used in North America, particularly in the United States.

115RE Rail Profile

115 re rail drawing

115RE Rail Dimensions

Type	Head Width (mm)	Rail Height (mm)	Base Width (mm)	Web Thickness (mm)	Weight (kg/m)
115RE (115lb)	69.06	168.28	139.7	15.88	56.9
